Radio Widget

Definition

The Radio Edit Widget allows to configure the edit of a string type by configuring a list of values.

The user will be able to choose one and only one value.

Radio Edit (STANDARD)	Radio Edit (BUTTON_GROUP)

Configuration

Properties

Property name	Type	Mandatory	Description	Values (default value in bold)
i18nPrefix	-	NO	Allows to define the first part of the i18n key for each configured id. If this property is used, you cannot use the <text> property, otherwise the translation not will be taken into account.	-
id	`String`	NO	Defines a unique id for each option.	-
inline	`Boolean`	NO	Defines if the buttons are inline or not. Only available for STANDARD style.	true, false
options	`List<RadioOptionType`>	NO	Allows to define one or several value(s) to choose.	-
radioStyle	`Enum`	NO	Defines the display of the buttons.	STANDARD, BUTTON_GROUP

options properties

Property name	Type	Mandatory	Description	Values (default value in bold)
option	`RadioOptionType`	NO	Defines the different values.	-

option properties

Each option will have the following configuration:

Property name	Type	Mandatory	Description	Values (default value in bold)
id	`String`	NO	Defines a unique id for each option.	-
text	`String`	NO , but necessary	Defines, for each id, the text that will be displayed to the user.	-

Example

Radio Edit

Radio Edit with i18nPrefix

CODE

<widget id="test_radio_edit" xsi:type="ctdbum:AttributeEditorWidgetType">
	<hidden>false</hidden>
    <config>
    	<editor>
        	<editWidget xsi:type="ctdbum:RadioEditWidgetType">
            	<hidden>false</hidden>
                <config>
                    <required>false</required>
                    <radioStyle>STANDARD</radioStyle>
                    <inline>true</inline>
                    <options>
                    	<option>
                        	<id>test_1</id>
                            <text>test_1</text>
                        </option>
                        <option>
                            <id>test_2</id>
                            <text>test_2</text>
                        </option>
                        <option>
                            <id>test_3</id>
                            <text>test_3</text>
                        </option>
					</options>
				</config>
			</editWidget>
		</editor>
        <label></label>
        <lockedInUi>false</lockedInUi>
        <mode>READ_WRITE</mode>
        <multiValued>false</multiValued>
        <override>true</override>
	</config>
    <attributeId>test_radio_edit</attributeId>
</widget>
