The Boolean Widgets allows to configure the display of boolean attributes.
This Widget do not allow the edition of a boolean attribute therefore there is no Edit mode for this Widget.
To configure the edition of a boolean attribute, Toggle or Check Box Widget can be used.
On/Off display | Icon display | True/False display |
|---|
 |  |  |
Properties name | Type | Mandatory | Description | Values (default value in bold) |
|---|
backgroundColor | String
| NO | The color displayed for the background. | Standard CSS color value, #ffffff |
bold | Boolean
| NO | Defines if the value is displayed in bold or not. | true, false |
fontSize | Enum
| NO | Defines the displayed size. | INHERIT, XX_SMALL, X_SMALL, SMALL, MEDIUM, LARGE, X_LARGE, XX_LARGE |
italic | Boolean
| NO | Defines if the value is displayed in italic or not. | true, false |
textAlign | Enum
| NO | Defines where the text is aligned when displayed. | LEFT, CENTER, RIGHT |
textColor | String
| NO | Defines the displayed color. | Standard CSS color value, #000000 |
underline | Boolean
| NO | Defines if the value is underlined or not. | true, false |
booleanDisplayType | Enum
| NO | Defines the display of the different values. | ICON, TRUE_FALSE, ON_OFF* |
falseIcon | String
| YES , if type is ICON | Defines an icon to display if boolean value is false. | https://fontawesome.com/v4.7.0/icons/ Example: <falseIcon>fa fa-times</falseIcon> |
falseText | String
| NO | Defines a text to display if boolean value is false. | |
trueIcon | String
| YES , if type is ICON | Defines an icon to display if boolean value is true. | https://fontawesome.com/v4.7.0/icons/ Example: <trueIcon>fa fa-check-square</trueIcon> |
trueText | String
| NO | Defines a text to display if boolean value is true. | |
Display - On/Off | Display - | Display - True/False (text) |
|---|
XML
<widget id="enabled" xsi:type="ctdbum:AttributeEditorWidgetType">
<hidden>false</hidden>
<config>
<editor>
<displayWidget xsi:type="ctdbum:BooleanDisplayWidgetType">
<hidden>false</hidden>
<config>
<backgroundColor>#ffffff</backgroundColor>
<bold>false</bold>
<fontSize>INHERIT</fontSize>
<italic>false</italic>
<textAlign>LEFT</textAlign>
<textColor>#000000</textColor>
<underline>false</underline>
<booleanDisplayType>ON_OFF</booleanDisplayType>
</config>
</displayWidget>
</editor>
<label></label>
<lockedInUi>false</lockedInUi>
<mode>READ</mode>
<multiValued>false</multiValued>
<override>true</override>
</config>
<attributeId>enabled</attributeId>
</widget>
|
XML
<widget id="enabled" xsi:type="ctdbum:AttributeEditorWidgetType">
<hidden>false</hidden>
<config>
<editor>
<displayWidget xsi:type="ctdbum:BooleanDisplayWidgetType">
<hidden>false</hidden>
<config>
<backgroundColor>#ffffff</backgroundColor>
<bold>false</bold>
<fontSize>INHERIT</fontSize>
<italic>false</italic>
<textAlign>LEFT</textAlign>
<textColor>#000000</textColor>
<underline>false</underline>
<booleanDisplayType>ICON</booleanDisplayType>
<trueIcon>fa fa-check-square-o</trueIcon>
</config>
</displayWidget>
</editor>
<label></label>
<lockedInUi>false</lockedInUi>
<mode>READ</mode>
<multiValued>false</multiValued>
<override>true</override>
</config>
<attributeId>enabled</attributeId>
</widget>
|
XML
<widget id="enabled" xsi:type="ctdbum:AttributeEditorWidgetType">
<hidden>false</hidden>
<config>
<editor>
<displayWidget xsi:type="ctdbum:BooleanDisplayWidgetType">
<hidden>false</hidden>
<config>
<backgroundColor>#ffffff</backgroundColor>
<bold>false</bold>
<fontSize>INHERIT</fontSize>
<italic>false</italic>
<textAlign>LEFT</textAlign>
<textColor>#000000</textColor>
<underline>false</underline>
<booleanDisplayType>TRUE_FALSE</booleanDisplayType>
</config>
</displayWidget>
</editor>
<label></label>
<lockedInUi>false</lockedInUi>
<mode>READ</mode>
<multiValued>false</multiValued>
<override>true</override>
</config>
<attributeId>enabled</attributeId>
</widget>
|
