Definition
A Field Editor works like an Attribute Editor to display and use a data not bound to an Attribute.
It is possible to configure Field Editors on a Screen, in a way similar to Attribute Editors, with associated rules. When the Feature is submitted, the field inputs are separate from the attribute inputs.
The values entered in the Field Editors are not stored in the database.
A Field Editor is configured to display or edit a field by using a dedicated Widget (date, text, number...).
A Field Editor can be used in Workflow with a double validation. In this case, a script task with a skip expression must be configured. The user task will not launch for a user (according to the configuration in the script task).
Configuration
This Widget defines how the attributes will be presented depending on the mode:
The configuration is similar to an Attribute Editor, only the widget id changes: "FieldEditorWidgetType" instead of "AttributeEditorWidgetType".
Example
Field Editor with Select Edit Widget | Field Editor with Advanced Object Reference |
|---|
CODE
<widget id="applyTo" xsi:type="ctdbum:FieldEditorWidgetType">
<hidden>false</hidden>
<config>
<editor>
<editWidget xsi:type="ctdbum:SelectEditWidgetType">
<hidden>false</hidden>
<config>
<defaultValue xsi:type="xs:string">Entity</defaultValue>
<required>true</required>
<options/>
<sort>AUTO</sort>
</config>
</editWidget>
</editor>
<label></label>
<lockedInUi>false</lockedInUi>
<mode>READ_WRITE</mode>
<multiValued>false</multiValued>
<choicesRule>
<script><![CDATA[
return ChoicesRuleResult.of("ui.model.fields.applyTo.values", ["Entity"])
]]></script>
</choicesRule>
</config>
<fieldId>applyTo</fieldId>
</widget>
|
CODE
<widget id="structuresToAdd" xsi:type="ctdbum:FieldEditorWidgetType">
<hidden>false</hidden>
<config>
<editor>
<editWidget xsi:type="ctdbum:AdvancedObjectReferenceEditWidgetType">
<hidden>false</hidden>
<config>
<required>true</required>
<popupAttributes>
<attribute>securityCode</attribute>
<attribute>mailContactUser</attribute>
<attribute>securityLabel_EN</attribute>
<attribute>securityLabel_FR</attribute>
</popupAttributes>
<search>
<actions/>
<allowExport>false</allowExport>
<columns>
<column>
<attribute>true</attribute>
<dataKey>securityCode</dataKey>
<dataType>string</dataType>
<dateFormat>DAY_MONTH_YEAR_LONG</dateFormat>
<ellipsis>false</ellipsis>
<hidden>false</hidden>
<sortAs>ALPHA</sortAs>
<sortDirection>ASC</sortDirection>
<sortable>true</sortable>
<sorted>true</sorted>
<type>general</type>
</column>
<column>
<attribute>true</attribute>
<dataKey>securityLabel_EN</dataKey>
<dataType>string</dataType>
<dateFormat>DAY_MONTH_YEAR_LONG</dateFormat>
<ellipsis>false</ellipsis>
<hidden>false</hidden>
<sortAs>ALPHA</sortAs>
<sortDirection>ASC</sortDirection>
<sortable>false</sortable>
<sorted>false</sorted>
<type>general</type>
</column>
<column>
<attribute>true</attribute>
<dataKey>securityLabel_FR</dataKey>
<dataType>string</dataType>
<dateFormat>DAY_MONTH_YEAR_LONG</dateFormat>
<ellipsis>false</ellipsis>
<hidden>false</hidden>
<sortAs>ALPHA</sortAs>
<sortDirection>ASC</sortDirection>
<sortable>false</sortable>
<sorted>false</sorted>
<type>general</type>
</column>
</columns>
<rowClickActions/>
<additionalSearchAttributes/>
<displayFrozenOperators>true</displayFrozenOperators>
<frozen>NO</frozen>
<modes>
<mode>MULTICRITERIA</mode>
<mode>SIMPLE</mode>
</modes>
<objectReferences/>
<searchExpression>
<search:And>
<search:Prop op="EQUALS_LIKE" name="securityCode"/>
<search:Prop op="CONTAINS_LIKE" name="securityLabel"/>
<search:Prop op="EQUALS" name="type"/>
</search:And>
</searchExpression>
</search>
<displayPopup>true</displayPopup>
<scope type="RULE" objectKind="ORGANIZATION" xsi:type="ctd:DynamicObjectScopeType">
<searchExpression/>
<rule>
<script><![CDATA[
def entities1 = expr {} as SearchExpression
def entities2 = ~ expr {} as SearchExpression
def searchExpression = expr { status.eq('NORMAL') }
OBJECT.roles.findAll { it.role == 'R20-ASL' && it.status == RoleAssignmentStatus.ASSIGNED }
.each { r -> entities1 = expr { entities1 & not(id.belowOrEquals(r.dimensions.roleStructure as String)) } }
if (SUBJECT.rights.any { it.name in ["adm.R20.PFA", "adm.R20.POA"] }) {
// renvoyer toutes les entités sur lesquelles le user n'est pas déjà ASL
if (entities1 == expr {}) {
return searchExpression
} else {
return expr { searchExpression & entities1 }
}
}
SUBJECT.rights.findAll { it.name == "adm.R20.STRUCTURE_DOMAIN_MANAGEMENT" }
.each { r -> entities2 = expr { entities2 | id.belowOrEquals(r.dimensions.structure as String) } }
SUBJECT.rights.findAll { it.name == "adm.R20.STRUCTURE_SCOPE_MANAGEMENT" }
.each { r -> if (r.dimensions.structure) { entities2 = expr {entities2 | id.belowOrEquals(r.dimensions.structure as String) } } }
// renvoyer toutes les entités sur lesquelles le user n'est pas déjà ASL et qui sont dans le périmètre du domain ou du scope
if (entities1 == expr {}) {
return expr { searchExpression & entities2 }
} else {
return expr { searchExpression & entities1 & entities2 }
}
]]></script>
</rule>
<objectTypes>
<objectType>zone</objectType>
<objectType>securityNode</objectType>
<objectType>department</objectType>
</objectTypes>
</scope>
</config>
</editWidget>
</editor>
<label></label>
<lockedInUi>false</lockedInUi>
<mode>READ_WRITE</mode>
<multiValued>true</multiValued>
</config>
<fieldId>structuresToAdd</fieldId>
</widget>
|
